Window Aluminum 45 Degree and 90 Degree Frame Cutting Machine Angle Cutting Machine Frame Saw Cutter Machine

45 &90 degree aluminum cutting machine angle cutter machine

1.The aluminum cutting machine is controlled by the imported pneumatic system, with good processing effect and stable and smooth cutting speed.
2. Used for aluminum alloy frame, edge band, photo frame, door and window, aluminum 45° cutting, equipped with standard ruler, accurate positioning; foot control, swaging position mechanism;
3.automatic waste disposal mechanism, easy to use, safe, fast.
4.The work surface is made of imported steel plate, and the surface of the table is 140mm thick. The cutting is precise and durable.
More information, welcome to inquiry:Aimee@kovimachine.com +86 15516916259

Model	KVL-305	KVL-355	KVL-405
Cutting angle	45 / 90 degree	45 / 90 degree	45 / 90 degree
Power	1.5kw	1.5kw	1.5kw
Voltage	220v/50hz	220v/50hz	220v/50hz
45 degree Maximum cutting size	Width 120mm Height 92mm	Width 140mm Height 110mm	Width 170mm Height 130mm
90 degree Maximum cutting size	Width 110mm Height 80mm	Width 120mm Height 100mm	Width 250mm Height 120mm
